Marcel Piping is a renowned manufacturer of ASME B16.5 flanges in India. The ANSI B16.5 standard encompasses pipe flanges and flanged fittings for sizes ranging from NPS ½” to 24”. For sizes above NPS 26” to 60”, the specifications follow ASME B16.47. Each specification classifies flanges into pressure classes: 150, 300, 400, 600, 900, 1500, and 2500 as per B16.5.
ASME B16.5 Class 400 Flange Dimensions, ANSI B16.5 Flange Dimensions, ASME/ANSI B16.5 Flanges, ASME B16.5 Flange Chart, ASME B16.5 Flange Bolting Chart
ANSI B16.5 Flange Face Finish, ASME B16.5 Flange Sizes, ANSI B16.5 Flange Materials, ASME B16.5 Flange Dimensions in mm, ASME B16.5 Flange Bolt Torque, ASME B16.5 Flange Rating Calculator
ASME / ANSI B16.5 Flange Specification
| Standard | ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings |
| Dimensions | 1/2″ (15 NB) to 48″ (1200NB) |
| Size | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc. |
| Type | DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673 |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
ANSI B16.5 Flange Material Specification:
Stainless Steel ASME B16.5 Flange:
ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L
Duplex & Super Duplex Steel ASME B16.5 Flange:
ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61
Carbon Steel ASME B16.5 Flange:
ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706
Low Temperature Carbon Steel ASME B16.5 Flange: ASTM A350, LF2, LF3
Alloy Steel ASME B16.5Flange:
ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91
Copper Alloy Steel Flange ASME B16.5: ASTM SB 61 , SB62 , SB151 , SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200
Nickel Alloy ASME B16.5 Flange:
ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020)
